Changzhou Changpeng Motor Co., Ltd.
6 Years
| Ask Lasest Price | |
| Brand Name : | CPMDJ |
| Model Number : | CP-100A/B |
| Certification : | CCC |
| Price : | Negotiable |
| Payment Terms : | TT, LC |
| Supply Ability : | 10000000 |
| Delivery Time : | 15-35 days |
4 Inch Inline Duct Fan Customized Industrial Centrifugal Elevator Exhaust Fan Inline Fan Flexible Exhaust Fan Blower
This series is a centrifugal type inline duct fan. It's made of plastic and houses a backward propeller.
This fan creates a very powerful airflow, which will quickly ventilate your target space, while bringing the temperatures and humidity down and/or clean the air in the grow room from smell and other pollutants through a carbon filter.
They will handle static air pressure very well. Keep in mind that with maximum air flow comes reasonable amount by the moving air, because of that we've built this model with a motor speed controller, which will allow you to select a desired level of output and the ratio between sound volume/airflow. The motor is adjustable between 100% to 50% of max output.
Features of Inline Duct Fan:
1:Heavy-Duty Metal Construction with Powerful 67W Motor Delivering 188 CFM OF AIRFLOW
2:Easy To Install With Included Metal Bracket or Mount Directly on the Carbon Filter
3:Built-In Motor Speed Control Allows Adjustment between 100%-50% of Max Motor Speed
4:Sleek Jet Black Design That Matches TerraBloom's Carbon Filters
| Type of Protection | IP44 |
| Bearing Type | Ball Bearing |
| Motor Type | Induction External Rotor Motor |
| Motor Insulation | B/F |
| Protection | Thermal Overload Prodector(Top)Wired Internally |
| Direction Of Rotation | Clockwise/See On The Lead |
| Approval | CE,UL,CCC |
| Amb.Temp | -10~+60℃ |
| Weight | 3-5KG |
Parameters of Inline Duct Fan:
| Model | Voltage | Frequency | Current | Power | Speed | Air Flow | Static pressure | Noise | Weight |
| V | Hz | A | w | r.p.m | CFM/m³/h | Pa | dB | KG | |
| CP-100A | 120V | 60Hz | 0.86 | 101 | 2900 | 183/310 | 560 | 50 | 3 |
| CP-100B | 230V | 50Hz | 0.3 | 70 | 2500 | 176/298 | 390 | 48 | 3 |
| CP-125A | 120V | 60Hz | 0.94 | 111 | 2700 | 266/450 | 550 | 55 | 3 |
| CP-125B | 230V | 50Hz | 0.32 | 71 | 2500 | 248/421 | 373 | 51 | 3 |
| CP-150A | 120V | 60Hz | 1.6 | 189 | 2450 | 465/788 | 650 | 59 | 4 |
| CP-150B | 230V | 50Hz | 0.5 | 120 | 2400 | 454/770 | 600 | 57 | 4 |
| CP-200A | 120V | 60Hz | 2.1 | 256 | 2550 | 678/1149 | 797 | 63 | 5 |
| CP-200B | 230V | 50Hz | 0.8 | 170 | 2450 | 637/1080 | 600 | 60 | 5 |
Use of Inline Duct Fan:
Application of Inline Duct Fan:
1.Freenhouse
2. Hydroponic
3. Kitchen
4. Workshop
5. House
6. Vessel
...
Our Service of Inline Duct Fan:
● Online service: we can talk on Trade manger , Email, Phone,
Wechat and so on.
● Customer service: we accept OEM,with your own design, brand and
label.
● Sample service:we will send samples for free, if you decide to
buy our product
● Presale service: We will try our best to answer you every
question in time.
● In-sale service: We will produce the goods with high quality; and pack carefully. We will also keep contact with you when the goods are ready for delivery until it reached safely.
● After-sale service:If you have any question, please contact us at any time
Packing and Delivery of Inline Duct Fan:
All our goods will be delivered 1 month after receiving your payment. The goods will be packed in a container, which one container including 5000pcs.We will inform you before we send out the product.
|
|
